PACK-EOL Testing Machine

Product Description:

• The Pack EOL test system is ideal for high-power lithium-ion battery tests.Test and verify possible failures and safety issues during the entire battery pack assembly process
• Complete PACK packet detection through dual-channel high and low voltage conversion

Test items

• PACK voltage (test the voltage of each point of PACK)
• Cell voltage difference (compare CAN read voltage difference)
• total voltage detection
• Box heating internal resistance detection (measure the resistance of the heating resistance)
• Heat dissipation Draught Fan detection (close the fan control relay, detect the voltage signal)
• Insulation detection (insulation between positive, negative,shells)
• Withstand voltage detection (withstand voltage between positive, negative, and shells)
• Equipotential testing
• Communication detection (can communication detection such as Acan, Ccan, etc.)
• Temperature detection (temperature value and number of temperature sensors in BMS, etc.)
• AC internal resistance (test PACK AC internal resistance)
• PWM signal

Technical Parameters:

Machine Show:

Schematic diagram of two channels
